N5K-C5548UP-FA Overview
N5K-C5548UP-FA is Nexus 5548 UP Chassis, including 32 fixed unified ports, Front-to-Back Airflow, 2 750W AC Power Supplies, Fan Trays, 1 Expansion Slot. Unified ports support traditional Ethernet, Fibre Channel (FC), and Fibre Channel over Ethernet (FCoE).
Quick Specs
Figure 1 shows the appearance of Cisco Nexus 5548UP, N5K-C5548UP-FA is its chassis.
Table 1 shows the Quick Specs of N5K-C5548UP-FA.
| Product Code | N5K-C5548UP-FA |
| Product Type | Switch Chassis |
| Ethernet Technology | 10 Gigabit Ethernet |
| Number of Total Expansion Slots | 33 |
| Expansion Slots | 1 |
| Expansion Slot Type | SFP+ |
| Performance | Layer 2 hardware forwarding at 960 Gbps or 714.24 mpps; Layer 3 performance of up to 160 Gbps or 240 mpps |
| Form Factor | 1RU |
| Fixed Ports | 32 fixed unified ports |
| Power Supplies | 2 x 750W AC Power Supplies |
| PoE (RJ-45) Port | No |
| Fan Modules | 2 |
| Airflow | Front-to-back (port-side exhaust) cooling；The Cisco Nexus 5548UP alternatively supports back-to-front (port-side intake) cooling (all fan and power supply modules in the same chassis must support the same direction of airflow) |
| Manageable | Yes |
| Physical (height x width x depth) | 1.72 x 17.3 x 29.5 in. (4.4 x 43.9 x 74.9 cm) |
| Weight（with two 1100W power supplies, 3 unified port expansion modules, and 4 fan modules） | 35 lb (15.88 kg) |
Product Details
Figure 2 shows the front panel of Cisco Nexus 5548UP. N5K-C5548UP-FA is its chassis.
Note:
| ① | ID LED |
| ② | Status LED |
| ③ | 32 fixed unified ports
Unified ports support traditional Ethernet, Fibre Channel (FC), and Fibre Channel over Ethernet (FCoE). |
| ④ | Expansion module |
Figure 3 shows the back panel of Cisco Nexus 5548UP. N5K-C5548UP-FA is its chassis.
Note:
| ① | ID LED |
| ② | Status LED |
| ③ | Management (10/100/1000) ports, console port, and USB port |
| ④ | Two fan modules |
| ⑤ | Two power supplies |
The Accessories
Table 2 shows the recommended elements for the N5K-C5548UP-FA.
| Category | Model | Description |
| Nexus 5500 Expansion Slot
|
N55-M16UP | Nexus 5500 Unified Ports Module 16p, Spare |
| Nexus 5500 L2 and L3 Options | N55-D160L3-V2 | Nexus 5548 Layer 3 Daughter Card, Version 2 |
| N5K Transceiver and Cable
|
SFP-H10GB-CU1M | 10GBASE-CU SFP+ Cable 1 Meter |
| SFP-H10GB-ACU7M | Cisco Direct-Attach Active Optical Cables with SFP+ Connectors, SFP-H10GB-ACU7M | |
| License | N55-48P-SSK9 | Nexus 5500 Storage License, 48 Ports |
Compare to Similar Items
Table 3 shows the comparison of N5K-C5548UP-FA, N5K-C5596UP-FA and N5K-C5596T-FA.
| Product Code | N5K-C5548UP-FA | N5K-C5596UP-FA | N5K-C5596T-FA |
| Form Factor | 1RU | 2RU | 2RU |
| Fixed Ports | 32 fixed unified ports | 48 fixed unified ports | 32x10GT/16xSFP+ Fixed Ports |
| Power Supplies | 2 750W AC Power Supplies | 2 1100W AC Power Supplies | 2 1100W AC Power Supplies |
| Fan Modules | 2 | 4 | 4 |
| Expansion Slots | 1 | 3 | 3 |
| Airflow | Front-to-Back | Front-to-Back | Back-to-Front |
